Entertain friends and family, enjoy day-long watersports or evening cruises - the 320 is ready for any on-water adventure. Cutting-edge features and convertible seating make this family-friendly dual console uniquely yours.
Cutting-edge features, great capacity and easy adaptability are hallmarks of the dual-console 320 Vantage®, winner of the National Marine Manufacturers Association's Innovation Award for it's convertible seating. Rock-solid control meets the ultimate in versatility and comfort with the many accessories and options the 320 provides. Serious fishing, joyful entertaining, day-long watersports or cruising and even a place to sneak in a nap or an overnight stay, the 320 is ready for your day. When the softest, safest ride meets the best equipped dual-console around, new possibilities become eminently possible. With Whaler, you can be confident to the core. Features may include:
EQUIPMENT
- All hardware 316-L stainless steel
- All rails welded 316-L stainless steel
DECK/COCKPIT
- 8" cleats
- 10" stainless steel pop-up cleats - (2) bow, (2) stern with stainless steel hawse pipes, (2) spring line
- 28" interior freeboard
- Anchor storage
- Anchor windlass with 200' of rode, chain, and anchor
- Bow and stern eyes
- Cockpit coaming bolsters
- Cockpit courtesy lights (dual color blue/white)
- Drink holders (stainless steel)
FIBERGLASS HARDTOP
- Grab rails, located on centerline (stainless steel)
- Mold in non-skid
- Navigation light
- Rod holders (4) (white or black depending on frame color)
- Tow bit (deleted with fishing package) (white or black depending on frame color)
- Welded aluminum integrated frame with tempered glass windshield with stainless steel top cap (white or black depending on frame color)
COCKPIT UTILITY CENTER
- Bank of drawers
- Battery switch panel
- Built-in storage
- Cutting board
- Dedicated trash can storage
BOW AREA
- 12-V receptacle
- Bow bolster
- Bow cushions with backrests
- Bow walkthrough block off panel
- Drink holders (4) - stainless steel
- Fiberglass lids with latches
- Folding armrests, port and starboard
PORT CONSOLE
- Convertible berth
- Dash visor
- Lighting - blue accent
- Lighting - interior light
STARBOARD CONSOLE
- Access panel to electronics
- Cast stainless steel steering wheel with urethane grip
- Compass
- Courtesy light
- Dash visor
SEATING
- Bow seating area with lounge backrests and armrests, port and starboard
- Deluxe custom helm seat with electric high/low pedestal
STORAGE
- Bow anchor locker with drain
- Cockpit storage center
- Head storage compartment
- Bow storage lockers, port and starboard drains
- Storage forward of helm on console
MECHANICAL
- 250 V8 DTS Black Dual Mercury Verado engines with hydraulic power steering
- 285-gallon fuel tank
- Automatic bilge pumps
- Dual battery trays with switch
- Electric horn
Dimensions
Overall Length Centerline: 32' 1" (9.78 m) | With platforms: 33' 6" (10.21 m)
Beam 10' 4" (3.15 m)
Draft 22" (0.56 m)
Transom Height 25" (0.63 m)
Dead Rise At Transom: 21°
Bridge Clearance With hardtop: 8' 9" (2.67 m) | With radar: 9' 7" (2.92 m)
Length Package Boat Specs (on trailer/engine up ): 45' 0"
Width Package Boat Specs (on trailer/engine up ): 10' 4"
Height Package Boat Specs (on trailer/engine up ): 12' 0"
Rear Livewell Capacity 18 gallons (68.1 L)
Fresh Water Capacity 30 gallons (113.5 L)
Black Water Capacity 6.5 gallons (24.6 L)
Capacities
Seating Capacity 14 Persons
Fuel Capacity 285 gallons (1,078 L)
Weight, Maximum Capacity 4,145 lbs. (1,880 kg) | Swamped: 4,825 lbs. (2,189 kg) | Engine: 1,400 lbs. (635 kg)
Weights
Dry Weight No engine: 9,800 lbs. (4,445 kg)
Weight With engine, fuel and water: 13,142 lbs (5,961 kg)
Engine
Engine Power Maximum: 800 HP (597 kW)
Minimum Engine Power 500 HP (372 kW)
Features
Features European Certification
